High Quality Self-Aligning Roller Bearings E-Type-Bearings 22252CC/W33 22252CCK/W33

< >

Product Details:

Place of Origin:	China
Brand Name:	KOYO NSK TDGS
Certification:	ISO9001:2000
Model Number:	22252CC/W33 22252CCK/W33

Payment & Shipping Terms:

Minimum Order Quantity:	1-99 Pcs
Price:	US$ 0.1-99
Packaging Details:	PAPER BOX,CARTON.WOODEN CASE
Delivery Time:	7-25 days
Payment Terms:	TT OR L/C
Supply Ability:	80,000 Pcs per Month

Detailed Product Description

High Quality Self-Aligning Roller Bearings E-Type-Bearings 22252CC/W33 22252CCK/W33

With two structures of bore cylindrical or tapered and retainers made of steel sheet or syntheticresins, the bearings are characteristic of compensate concentricity and deflection errors.The bearings are available in open and sealed versions.Self-aligning ball bearings are for heavy load and shock load , precision instruments, low noise motors, automobiles, motorcycles, metallurgy, mill, mining, petroleum, paper, cement, sugar, and other common machinery.

High Quality Self-Aligning Roller Bearings E-Type-Bearings 22252CC/W33 22252CCK/W33

Boundary dimensions(mm)				Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)	Bearing Number
d	D	B	rs min	Cr	Cor	Grease	Oil	(Approx.)	TDGS
180	320	86	4	1,040	1,610	920	1,400	29.3	22236W33C3
190	340	92	4	1,160	1,810	860	1,300	36.6	22238
190	340	92	4	1,160	1,810	860	1,300	35.8	22238K
190	340	92	4	1,160	1,810	860	1,300	35.8	22238KW33C3
190	340	92	4	1,160	1,810	860	1,300	36.6	22238W33C3
200	360	98	4	1,310	2,010	820	1,300	44	22240
200	360	98	4	1,310	2,010	820	1,300	43	22240K
200	360	98	4	1,310	2,010	820	1,300	43	22240KW33C3
200	360	98	4	1,310	2,010	820	1,300	44	22240W33C3
220	400	108	4	1,580	2,460	730	1,100	60.4	22244
220	400	108	4	1,580	2,460	730	1,100	59.1	22244K
220	400	108	4	1,580	2,460	730	1,100	59.1	22244KW33C3
220	400	108	4	1,580	2,460	730	1,100	60.4	22244W33C3
240	440	120	4	1,940	3,100	660	1,000	81.7	22248
240	440	120	4	1,940	3,100	660	1,000	80	22248K
240	440	120	4	1,940	3,100	660	1,000	80	22248KW33C3
240	440	120	4	1,940	3,100	660	1,000	81.7	22248W33C3
260	480	130	5	2,230	3,600	610	930	106	22252
260	480	130	5	2,230	3,600	610	930	104	22252K
260	480	130	5	2,230	3,600	610	930	104	22252KW33C3

Boundary dimensions(mm)				Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)	Bearing Number
d	D	B	rs min	Cr	Cor	Grease	Oil	(Approx.)	TDGS
260	480	130	5	2,230	3,600	610	930	106	22252W33C3
280	500	130	5	2,310	3,800	560	860	112	22256
280	500	130	5	2,310	3,800	560	860	110	22256K
280	500	130	5	2,310	3,800	560	860	110	22256KW33C3
280	500	130	5	2,310	3,800	560	860	112	22256W33C3
300	540	140	5	2,670	4,350	510	790	141	22260
300	540	140	5	2,670	4,350	510	790	138	22260K
300	540	140	5	2,670	4,350	510	790	138	22260KW33C3
300	540	140	5	2,670	4,350	510	790	141	22260W33C3
25	52	18	1	36.5	36	6,500	10,000	0.182	22205KW33C3
25	52	18	1	36.5	36	6,500	10,000	0.186	22205W33C3
30	62	20	1	49	49	5,700	8,800	0.287	22206
30	62	20	1	49	49	5,700	8,800	0.282	22206K
30	62	20	1	49	49	5,700	8,800	0.282	22206KW33C3
30	62	20	1	49	49	5,700	8,800	0.287	22206W33C3
35	72	23	1.1	69.5	71	4,900	7,500	0.446	22207
35	72	23	1.1	69.5	71	4,900	7,500	0.437	22207K
35	72	23	1.1	69.5	71	4,900	7,500	0.437	22207KW33C3
35	72	23	1.1	69.5	71	4,900	7,500	0.446	22207W33C3
40	80	23	1.1	79	88.5	4,300	6,600	0.526	22208
