Self-aligning roller bearings 23222CC/W33 23222CCK/W33 23222-2CS5/VT143

< >

Product Details:

Place of Origin:	China
Brand Name:	KOYO NSK TDGS
Certification:	ISO9001:2000
Model Number:	23222CC/W33 23222CCK/W33 23222-2CS5/VT143

Payment & Shipping Terms:

Minimum Order Quantity:	1-99 Pcs
Price:	US$ 0.1-99
Packaging Details:	PAPER BOX,CARTON.WOODEN CASE
Delivery Time:	7-25 days
Payment Terms:	TT OR L/C
Supply Ability:	80,000 Pcs per Month

Detailed Product Description

Self-aligning roller bearings 23222CC/W33 23222CCK/W33 23222-2CS5/VT143

With two structures of bore cylindrical or tapered and retainers made of steel sheet or syntheticresins, the bearings are characteristic of compensate concentricity and deflection errors.The bearings are available in open and sealed versions.Self-aligning ball bearings are for heavy load and shock load , precision instruments, low noise motors, automobiles, motorcycles, metallurgy, mill, mining, petroleum, paper, cement, sugar, and other common machinery.

Boundary dimensions(mm)				Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)	Bearing Number
d	D	B	rs min	Cr	Cor	Grease	Oil	(Approx.)	TDGS
150	270	96	3	935	1,460	1,000	1,600	23.4	23230K
150	270	96	3	935	1,460	1,000	1,600	23.4	23230KW33C3
150	270	96	3	935	1,460	1,000	1,600	24.1	23230W33C3
160	290	104	3	1,050	1,660	960	1,500	30	23232
160	290	104	3	1,050	1,660	960	1,500	29.1	23232K
160	290	104	3	1,050	1,660	960	1,500	29.1	23232KW33C3
160	290	104	3	1,050	1,660	960	1,500	30	23232W33C3
170	310	110	4	1,180	1,960	910	1,400	36.8	23234
170	310	110	4	1,180	1,960	910	1,400	35.7	23234K
170	310	110	4	1,180	1,960	910	1,400	35.7	23234KW33C3
170	310	110	4	1,180	1,960	910	1,400	36.8	23234W33C3
180	320	112	4	1,230	2,000	850	1,300	39	23236
180	320	112	4	1,230	2,000	850	1,300	37.8	23236K
180	320	112	4	1,230	2,000	850	1,300	37.8	23236KW33C3
180	320	112	4	1,230	2,000	850	1,300	39	23236W33C3
190	340	120	4	1,400	2,330	790	1,200	47.6	23238
190	340	120	4	1,400	2,330	790	1,200	46.2	23238K
190	340	120	4	1,400	2,330	790	1,200	46.2	23238KW33C3
190	340	120	4	1,400	2,330	790	1,200	47.6	23238W33C3
200	360	128	4	1,610	2,640	750	1,200	57.2	23240

Boundary dimensions(mm)				Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)	Bearing Number
d	D	B	rs min	Cr	Cor	Grease	Oil	(Approx.)	TDGS
200	360	128	4	1,610	2,640	750	1,200	55.5	23240K
200	360	128	4	1,610	2,640	750	1,200	55.5	23240KW33C3
200	360	128	4	1,610	2,640	750	1,200	57.2	23240W33C3
220	400	144	4	2,010	3,350	670	1,000	80	23244
220	400	144	4	2,010	3,350	670	1,000	77.6	23244K
220	400	144	4	2,010	3,350	670	1,000	77.6	23244KW33C3
220	400	144	4	2,010	3,350	670	1,000	80	23244W33C3
240	440	160	4	2,430	4,100	610	940	108	23248
240	440	160	4	2,430	4,100	610	940	105	23248K
240	440	160	4	2,430	4,100	610	940	105	23248KW33C3
240	440	160	4	2,430	4,100	610	940	108	23248W33C3
260	480	174	5	2,760	4,700	560	860	141	23252
260	480	174	5	2,760	4,700	560	860	137	23252K
260	480	174	5	2,760	4,700	560	860	137	23252KW33C3
260	480	174	5	2,760	4,700	560	860	141	23252W33C3
280	500	176	5	2,930	5,150	510	790	150	23256
280	500	176	5	2,930	5,150	510	790	145	23256K
280	500	176	5	2,930	5,150	510	790	145	23256KW33C3
280	500	176	5	2,930	5,150	510	790	150	23256W33C3
300	540	192	5	3,450	6,000	470	730	193	23260

Tag :

self-aligning ball bearing, rolling mill bearing
