UCT 211 Stainless Steel, UCK Series Pillow Blocks

< >

Product Details:

Place of Origin:	China
Brand Name:	HDBB NTN SKF
Certification:	ISO9001:2000
Model Number:

Payment & Shipping Terms:

Minimum Order Quantity:	100 PCS
Price:
Packaging Details:	PAPER BOX,CARTON.WOODEN CASE
Delivery Time:
Payment Terms:	TT OR L/C
Supply Ability:	10000 per month

Detailed Product Description

UCT 211 Stainless Steel, UCK Series Pillow Blocks

Introduction

Pillow blocks, the most commonly used type of mounted units, are designed to provide shaft support where the mounting surface is parallel to the shaft axis. The bolt holes are usually slotted for adjustment during mounting. Pillow blocks are supplied in a variety of configurations. Pressed steel pillow block bearings are also available for light-duty applications.

Quick Detail:

1. Long life
2. Sealing property fine
3. Timely delivery

4. Can withstand shoulders greatly
5. Sealing property fine

6. Timely delivery

7. Competitive price

The size include:

2 series and 3 series

part of them are listed below

Boundary dimensions(mm)			Block dimensions(mm)						Bearing Number
d	B	S	A	A1	H	H1	L	L1	HDBB	NTN
d	B	S	max	A1	max	H1	max	max	HDBB	NTN
20	31	12.7	51	13.5	94	76	104	69	UCK 204	UCT 204
40	49.2	19	67	17.5	124	101	146	91	UCK 208	UCT 208
55	55.6	22.2	72	27	152	130	191	120	UCK 211	UCT 211
25	38	15	36	12	89	80	122	76	UCK 305	UCT 305
60	71	26	71	22	178	160	220	135	UCK 312	UCT 312
85	96	40	102	32	240	214	298	183	UCK 317	UCT 317
130	135	54	150	50	385	350	465	285	UCK 326	UCT 326

Competitive Advantage

1 Quality level: reach the same level as the Japanese and European bearings

2 quick delievery, with large in stock.
